Ideal Applications
Internal keyways in shafts
External key seats on hubs
Woodruff key seats
O-ring face seal widths
Snap ring widths
All parallel surfaces
Notable Features
Fast, repeatable, spring-loaded contact points
High accuracies ±0.000040″/0.001mm
Repeatability <0.000040″
Non-tipping, no operator error
Mechanical or electronic for SPC
Exact measurement displayed
Dedicated sizes
How to Order
Send Dyer Application Engineering a marked-up print and we will quickly respond with a gage to fit your needs.
Gage assembly requires the following:
Keyway gage head
Holder
Indicator (digital dial)
Parallel setting master
